A6500-SR System Rack

A6500-SR System Rack ke karolo ea sistimi ea ts'ireletso ea mochini ea AMS 6500 ATG.Ke rack ea 19 "(bophara ba 84HP le bophahamo ba 3RU).The System Rack e u lumella ho kenya likarete tsa ts'ireletso tse fihlang ho 11 (karete e 'meli ea A6500-UM Universal Measuring Card le/kapa likarete tse nne tsa A6500-TP Temperature Process Cards), likarete tsa Relay tsa A6500-RC, le A6500-CC Com Card e le 'ngoe. Com Cards bakeng sa puisano e sa hlokahaleng.

Karolo e ka morao ea System Rack e na le likhokahano tsa "push-in spring cage" ho hokahanya mats'oao a ho kenya le ho tsoa, ​​​​ka likhokahano tsa D-Sub ho fana ka matšoao a tala a sensor le li-slide switch ho lokisa matšoao a senotlolo le lisebelisoa tsa binary.E 'ngoe le e' ngoe ea li-slots tse 11 bakeng sa likarete tsa ts'ireletso e na le likhokahano tse 'ne tsa lipoleiti tse robeli tsa selemo bakeng sa ho hokahanya mefuta e mengata ea li-sensor (li-sensor tsa eddy tsa hajoale, li-piezoelectric sensors, sensors tsa seismic, RTDs, joalo-joalo), li-input, liphetho tsa binary (liphetho tsa ts'ebetso), liphetho tsa hajoale. , le liphello tsa pulse.Palo e teng ea likanale tsa ho metha le lits'ebetso tse ling kaofela li itšetlehile ka likarete tse kentsoeng.U ka atolosa tsamaiso ka Rack ea bobeli ea System ho ea tsamaiso ea 6RU.Tabeng ena, Com Card(s) ea raka ea pele e sebelisoa bakeng sa bobeli System Racks.Motlakase oa Phatlalatso ea Phatlalatso ea Matla +24V DC e sa hlokeng moeli +19 ho +32V DC ha ho ka hlōleha hanngoe feela, motlakase oa phepelo ha oa lokela ho feta boemo ba IEC 60204-1 kapa IEC 61131-2 (SELV/PELV) Tšebeliso ea Matla a Slots < 100W ea likarete tse kentsoeng Liphetho tsa Tšebeliso ea Matla <150W phepelo e eketsehileng bakeng sa tšebeliso ea kantle ea liphetho tsa dijithale Palo ea Phano ea Kabelo ea Measurement Card Slots (A6500-UM le A6500-TP) 11 (sekotjana se seng le se seng 6HP) Palo ea Relay Card Slots 1 (sekotjana se seng le se seng 10HP) Palo ea COM Card Slots 2 (sekotjana se seng le se seng 4HP, ha se na thuso)
